Technical advantages
1. LED lights help customer for better observing printing quality and color bar .
2.Printhead cleaning system is perfect designed for single or multiple printhead cleaning.
3.100W DC servo motor.equipped 1000 sting American Agilent decoder, with specialized control chip,frequency of signal 4, achieve the precise control of media stepper. RBI signal sampling adopting.
4.Four-in-one integrate temperature control with LED window is easy to set up expected temperature and maintain a constant temperature in a user-friendly operation.
5.Adjustable Automatic Media Feeding & Take-up System helps statisfy with stability.
6.we can place 6 printers into one 40’ container = save the freight cost = save the incoming price.
7.Machine precision control:All on the marble flat (6000mm±0.01mm) to have beeline check.
Model |
SOLVENT KONICA HDK-3208 |
Color |
C , M , Y , K (4C) |
Printhead |
Konica Head |
Top Resolution |
UP TO 1440dpi |
Speed |
2pass 72m2/h 3pass 58m2/h 4pass 30m2/h (8 PCS KM512LN printhead) |
Media |
Paper/Advertising banner/PVC/Adhensive vinyl and so on |
Media printing width |
Maximum Printing Area：
3.2m(126 inch) |
| Media handing |
Roll to Roll |
Image format |
Tiff,Jpeg,Postscript3,EPS,PDF and so on |
Ink |
Solvent-based ink |
Printing software |
Photoprint 10 /Seeget/Ultraprint |
Optional |
1.Automatic printhead maintenance system (optional)
2.Media take-up system
3.Carriage up and down system |
Dimensions (W x D x H) |
4.57 x 0.88 x 1.65 （M） |
Net & Gross |
600kg & 800kg |
Package dimensions (W x D x H) |
4.85 x 0.74 x 1.10 (M) (removable) |
Control station |
Windows 2000 workstation / Windows XP/Vista/Window7 32bit |
Operation environment |
Power Supply:,AC,50HZ/60HZ , 220v(±10%)>15A
Distortion:<0.5% Temperature:20?~30? Humidity:40%~70% |
Safety Certification |
CE Certification |
Specifications subject to change without notice.
